Optical Transducer Trainer Useful, low cost, multi-purpose, mini-lab for all basic experiments in linear, digital & hybrid circuits using Optical Transducer Trainer • Low Cost • Multi purpose Mini Lab • Solderless Experiments possible • 2mm Inter Connection • Multi output DC Regulated Power Supplies with short circuit protection • Detailed Manual • 2 mm Stackable Patch Cords 2925....Product Code: ELABEEE111001 - (Optical Transducer Trainer)
Strain Gauge Transducer Trainer designed to study the Strain Gauge Transducer as a Direct Weighing machines to observe the effect of weight on the strain or resistivity of the Strain Gauge.
Pressure Transducer Trainer to measurement of Air Pressure using strain gauge.
A very good quality pressure sensor strain gauge based is used to measure the pressure and 3½ digital display for pressure indicator.
Range of pressure gauge is 0-10kg /cm2 and maximum capacity is 2kg /cm2 .
A mechanical pressure pump with oil tank is used for apply the pressure This
sensor forms a part of wheat stone bridge and with the help of signal conditioning provided in the panel measures air pressure with an accuracy of ±2%.
Power requirements 230V/50Hz.....
Temperature Transducer Trainer with Temperature controlled oven with digital display, Instrumentation amplifier with gain switching, Digital voltmeter, Interfacing circuits for common transducers
A transducer in a device which converts the temperature information into an electrical signal, usually voltage, for an automated processing. A very wide variety of temperature transducers are commonly available which differ from each other with regards to there:
a) Range of operation
b) Sensitivity and linearity
c) Accuracy, Stability and Repeatability
d) Speed of response
The present experiments has been designed to study the input-output characteristics of some common transducers like, thermistors (PTC and NTC), thermocouple, semiconductor sensors and may be extended to also study the temperature coefficients of resistances.
The main requirements for an experiment of this nature are,
a) A precisely controlled from oven with a temperature display which is fast
b) An adjustable gain instrumentation amplifier which may be used to amplify the different levels of signals from transducers
c) Interfacing circuits suitable for the transducers used
Temperature-output voltage characteristics of the following transducers in the temperature range of room temperature to 150º C and determination of their parameters
Chromel - Alumel thermocouple
Copper - Constantan thermocouple
Thermistors - Positive Temperature Coefficient
- Negative Temperature Coefficient
Semiconductor sensor (type AD590), upto 90ºC only
Features and Specifications
Temperature controlled oven upto 150ºC with digital temperature display
Digital voltmeter on the panel for sensor output measurement
Built-in interfacing circuit and switched gain instrumentation amplifier
LVDT Transducer Trainer - Study of Linear Variable Differential Transducer (L.V.D.T.) Instrumentation trainer has been designed specifically for to study Linear Variable Differential Transducer (L.V.D.T.). The board is absolutely self contained & require no other apparatus. Practical experience on this set up carries great educative value for Science and Engineering Students. The instrumentation trainer consists of the following
Transducer & Instrumentation Trainer - Rugged, self - contained panel trainer with a steel case and integral power supplies. Transducer & Instrumentation Trainer include Transducer input devices, Transducer output devices and Instrumentation circuitry.
Input devices:For the detection of rotary and linear position, temperature, light, pressure, strain, airflow, humidity and audible and Ultrasonic sound
For the generation of heat, light, rotary and linear actions, audible and ultrasonic sound and visual indication of voltage, time and number of events.
Instrumentation circuitry:For the investigation of Wheatstone Bridges and current measurement techniques, linear and non-linear signal amplification, closed and open loop control, one, two and three term (PID) control, DC restoration of AC signals, signal transmission techniques and alarm generation.
Manual provided covers the following topic areas :
An introduction to basic control systems.
An evaluation of the various Input devices.
Practical investigation of the various output devices.
Practical investigation of the Display devices.
Applications in practical systems, evaluation of input requirements.
In depth investigation / analysis of the numerous signal conditioning circuits.
Investigation of control system characteristics (On/Off,
Proportional, Proportional + Derivative & Proportional + Integral + Derivative)
Design and implementation of speed control systems, positional control systems, temperature control systems and light level control systems.
Includes the following items:
Instrumentation and Transducer Trainer
4 mm Lead set
Mini Process Control Demonstrator endows students and industry professionals to understand the concepts and working of thermal process control which enables them to learn advance and more complex thermal process; and contribute in the growth of instrumentation arena. It formulates students to accumulate, develop and practice the fundamentals of thermal process control.
Mini Process Control Demonstrator has sensors like temperature sensor, liquid level sensor, level indicators. It has safety measures such as emergency shutdown and overheat protector. There is a wide range of experiments that can be performed on the trainer. It also has computer interfacing with real time graphical analysis which helps to perform mathematical calculations required to state stability of process using methods like root locus, bode plot, etc..... Product Code: ELABEEE111007 - (Mini Process Demonstrator)
Level control trainer is designed for understanding the basic principles of level control. The process setup consists of supply water tank fitted with pump for water circulation. The level transmitter used for level sensing is fitted on transparent process tank. The process parameter (level) is controlled by microprocessor based digital indicating controller which manipulates pneumatic control valve through I/P converter. A pneumatic control valve adjusts the water flow in to the tank. These units along with necessary piping are fitted on support housing designed for tabletop mounting.
The controller can be connected to computer through USB port for monitoring the process in SCADA mode.
Product is supplied with 32 point demo version of SCADA software package.
Flow control trainer is designed for understanding the basic principles of flow control. The process setup consists of supply water tank fitted with pump for water circulation. A DP transmitter is used for flow sensing which measures differential pressure across orifice meter. The process parameter (flow) is controlled by microprocessor based digital indicating controller which manipulates pneumatic control valve through I/P converter. The control valve is fitted in water flow line.
These units along with necessary piping are fitted on support housing designed for tabletop mounting.
The controller can be connected to computer through USB port for monitoring the process in SCADA mode.
Product is supplied with 32 point demo version of SCADA software package....
Temperature control trainer is designed for understanding the basic temperature control principles. The process setup consists of heating tank fitted with SSR controlled heater for on-line heating of the water. The flow of water can be manipulated and measured by rotameter. Temperature sensor (RTD) is used for temperature sensing. The process parameter (Temperature) is controlled by microprocessor based digital indicating controller which manipulates heat input to the process. These units along with necessary piping and fitting are mounted on support frame designed for tabletop mounting.
The controller can be connected to computer through USB port for monitoring the process in SCADA mode.
Product is supplied with 32 point demo version of SCADA software package.....
The Pressure Control Trainer has been
designed to demonstrate and provide student’s
hands on experience on how a pressure loops
can be controlled using a microprocessor
based controller. The equipment consists
of industrial grade instrumentation to exhibit
a realistic working environment of standard
industrial pressure control loop.
The equipment is self - contained constructed on
an epoxy coated mild steel frame with
four lockable castor wheels. The tank,
instrumentation and values are strategically located for easy access. For safety reasons, the control panel is protected against water splashes. The process piping is made of industrial pipes.
The system exhibits realistic response times using standard industrial process instruments widely used in industries.
All electrical wiring is laid in flexible PVC conduit and instrument cables are screened. Identification tags are provided for every major item found in the equipment....
his system uses a comprehensive approach to cover such topics as sensors, transducers, signal conditioning, Visual Basic, application development, and system integration. Basic signal conditioning is explored through a visible system on modular application PCBs that are inserted into the base station. The student can use a variety of signal condition techniques to process the signal before it can be acquired by the PC computer....Product Code: ELABEEE111012 - (Data Acquisition Trainer)
Keeping in mind the changing requirements of customers, we are involved in offering utmost quality of Stepper Motor Control Trainer. This Stepper Motor Control Trainer is known for its world class quality and long functional life. On the other hand, this Stepper Motor Control Trainer is highly demanded by clients due to its perfect finishing and effective results.
We are amongst the chief manufacturer and supplier of varied assortment of premium quality Motor Control Center. This system is manufactured using utmost quality material and most modern technology resulting in robustness and longer functional life. This offered product is widely appreciated due to customized solutions for our esteem clientele. Thanks to low maintenance, sturdy construction and consistency, this system is very much appreciated by our clientele over the others. Owing to affordable price range, this system is widely in demand in the market.
Conveyors are basically material handling equipments. Conveyors
are used for moving materials over a fixed path. There is a broad
range of types of conveyor systems. Wheel conveyor, Roller
conveyor, Chain conveyor, Magnetic conveyor, Pneumatic conveyor
are some the major types.
Conveyors are used :
Conveyor Control by PLC is a Flat Belt Conveyor system. It consists of two Sensors. One is IR Sensor and other is Proximity Sensor. Belt is driven by a DC motor. Output of Proximity Sensor, output of IR Sensor are the inputs of PLC and motor Motor direction and buzzer are the outputs of PLC. Some additional I/Os also given for user.
Temperature Control enables Students and practicing Engineers to gain invaluable practical experience of the principles and application of analog module in PLC. The objective is to have the clear and better understanding of how analog signals are interfaced and controlled with PLC. Temperature Control by PLC has two Temperature Sensors which sense Temperature of heater, For cooling a fan is provided on top of the heater which can be switched ON / OFF as needed. Sensor 1gives output in terms of voltage with respect to Temperature, and Sensor 2 gives output in terms of Current (4-20 mA) with respect to Temperature. The apparatus is connected with analog input and output of PLC. Users can connect the analog input and output of PLC with Temperature Sensor with the help of 2mm patch cords and can program this board with the help of PLC software.
Water level control enables Students and
practicing Engineers to gain invaluable practical experience of
the principles and application of Programmable Logic
The objective is to connect and program an external
Programmable Logic Controller to monitor and control the level
of water in a tank system.
Water level controlling is shown with the help of LEDs. The module is connected with output of PLC. Two valves for filling and draining water are shown, for indicating ONOFF condition of valve LED is used. Filling of tank is indicated by two sensors positioned to sense maximum and minimum water levels of tank.
As a reputed firm, we are engaged in exporting, trading, manufacturing
and supplying a wide range of Traffic Light Control By PLC. Traffic
light control enables students and practicing engineers to gain
invaluable practical experience of the principles and application of
programmable logic controllers. The object is to connect and program an
external programmable logic controller to monitor and control the
traffic light system. Traffic light controlling is shown with the help
of LEDs. The apparatus is connected with output of PLC. Four way traffic
is automatically controlled by PLC roads which meeting at a circle.
Technical Specifications :-
Interface : 20 pin FRC cable needed with PLC (ST2401 A / B / C)
Input pin voltage : 24 V DC when particular i/p is activated from PLC
Output pin voltage : 5 V DC when particular o/p is activated from PLC
Power Supply : From PLC Traine....
....Product Code: ELABEEE111023 - (Magnetic Levitation Control Trainer)
ㆍPractices and experiments on Servo motor control techniques using Servo Driver
ㆍAluminum carrying case for convenient storage and mobility
ㆍJOG operation, PLC control operation, PC control operation
ㆍVarious types of control elements easily to be mounted
ㆍCapable of checking normal operating voltage / over current by the voltmeter and ammeter....
In control system there are different types of controller. Study of two-position mode as ON/OFF controller and continuous controller modes as PID controller is a very important part of control engineering. To have a basic idea and practical hands on controllers our PID Trainer has been designed to be used by student to investigate the fundamental principles of PID by applying different signals to it.
PID controller trainer student can study two position mode as ON/OFF
controller and continuous controller modes as P-control
mode, I-control mode, D control mode, PI-control mode, PD - control mode and PID control mode. This modes of controller can be performed individually and also with different combinations in open loop and close loop system. With this trainer user can easily understand the difference between the different modes of controllers used. Square wave, triangular wave generator and variable DC supply as set point is given on board and disturbance generator is provided. Effect of PID can be seen on first order system and second order system in open loop and close loop system, which is given on the board.
Analog to digital converter
Digital to analog converter
Backed by technologically advanced manufacturing unit, we have been able to offer our clients a qualitative range of Relay Control Trainer. Ensures trouble-free functionality to our clients, offered product is manufactured by our adept professionals at our well-equipped processing unit using supreme quality components as per the defined industry standards. This product is mainly used in diverse industries for controlling various process. Apart from this, offered Relay Control Trainer is made available in various technical specifications at reasonable prices.
High operational fluency
....Product Code: ELABEEE111031 - (Inverted Pendulum Control Trainer)
The Ball & Beam control system is a classic control teaching aid especially designed for courses in automatic control principle, modern control engineering, and electrical motor control — with operating characteristics typical of inherently unstable systems, as found in aircraft, ships and robots for example.
The Ball & Beam control system designed by Googoltech is able to control the position of a stainless steel ball on the track by adjusting the rotating angle of a beam. It consists of a v-grooved steel bar and a free rolling ball. The linear sensor measures the position of the ball on the track by measuring the output voltage from the stainless steel bar. A DC motor is connects to a gear reducer, which controls the angle of beam, accordingly realize the position control of the ball.
A dynamic and visually-motivating system, the Ball & Beam control system gives an impressive insight into the power of control theory..... Product Code: ELABEEE111032 - (Ball & Beam Control Trainer)
The Programmable Logic Controller Trainer are powerful and flexible
systems ideally suited to your specialized needs. Panasonic’s is a
leader in industrial automation and many factories commonly use their
products. The systems in our
trainers are compatible with a variety of accessories and peripherals,
thus allowing them to be easily expanded into larger systems. This
trainer is suitable for the students to develop competence in operating,
programming, and troubleshooting modern PLC control circuits. Several
models of trainers are available in different sizes. These trainers are
Basic Training Package, intermediate training package and advanced
training package according to their difficulty level and equipments
needed. A student experiment
manual is provided to guide the student through the experiments. The
experiments are chosen to cover the topics from basic familiarization of
the PLC up to programming and applications.
The Programmable Logic Controller Trainer are powerful and flexible systems ideally suited to your specialized needs. Panasonic’s is a leader in industrial automation and many factories commonly use their products. The systems in our trainers are compatible with a variety of accessories and peripherals, thus allowing them to be easily expanded into larger systems. This trainer is suitable for the students to develop competence in operating, programming, and troubleshooting modern PLC control circuits. Several models of trainers are available in different sizes. These trainers are Basic Training Package, intermediate training package and advanced training package according to their difficulty level and equipments needed. A student experiment manual is provided to guide the student through the experiments. The experiments are chosen to cover the topics from basic familiarization of the PLC up to programming and applications.
Electrical Power Utilization Trainer
Large energy consumers like industrial plants, processing plants and manufacturing units are required to provide compensation for reactive power used by them. Modern electrical control circuits also generate harmonics in the network.
This laboratory addresses the topics like reactive power compensation, reactive power controllers, measurement of electrical energy in three phase networks, cost of power consumed by the customers. These topics are analyzed from the theoretical point of view and also by means of practical examples.
Power Supplies Included
Flexibility to Perform Custom Experiments
Passive Components Included
Resistors, Capacitors and Inductors Included
Control Circuits Included
P.T. and other Passive Components Included
Protection Circuits Included.... Product Code: ELABEEE111034 - (Electrical Power Utilization Trainer)
